material：UPVC CPVC ANSI SCH80
|
Size
|
D
|
d1
|
d2
|
I
|
d
|
L
|
|
1/2"
|
30.60
|
21.54
|
21.23
|
24.22
|
16.50
|
6.50
|
|
3/4"
|
38.00
|
26.87
|
26.57
|
27.40
|
22.00
|
8.00
|
|
1"
|
45.50
|
33.66
|
33.27
|
30.58
|
28.00
|
8.00
|
|
1-1/4"
|
56.00
|
42.42
|
42.04
|
34.75
|
35.00
|
10.00
|
|
1-1/2"
|
62.40
|
48.56
|
48.11
|
37.93
|
43.00
|
12.00
|
|
2"
|
73.00
|
60.63
|
60.17
|
41.10
|
54.00
|
16.00
|
|
2-1/2"
|
90.00
|
73.38
|
72.85
|
47.45
|
69.00
|
18.00
|
|
3"
|
107.00
|
89.31
|
88.70
|
50.63
|
84.00
|
20.00
|
|
4"
|
132.50
|
114.76
|
114.10
|
60.15
|
100.00
|
26.00
|
|
5"
|
163.50
|
141.81
|
141.05
|
70.00
|
136.00
|
38.50
|
|
6"
|
191.00
|
168.83
|
168.00
|
79.20
|
150.00
|
45.00
|
|
8"
|
246.00
|
219.84
|
218.69
|
104.60
|
200.00
|
51.00
|
|
10"
|
307.00
|
273.81
|
272.67
|
130.00
|
265.00
|
60.00
|
|
12"
|
364.00
|
324.61
|
323.47
|
155.00
|
315.00
|
73.00
|
|
14
|
397.00
|
356.49
|
355.22
|
180.00
|
346.00
|
150.00
|
